Mar 17

Gear Tree

GearTree

Gears were designed (well, generated by a plug-in) in Inkscape and milled with CNC.

What is the purpose of this project?

Xenia needed it for school. No, not for science. It is for English writing, believe me or not.

Feb 09

Animation

How to create sprite animation on a web page?
Well, there are definitely multiple ways of doing it.
How about being cool?
What do the cool dudes do nowadays?
They write in HTML5 with libraries like KineticJS.
Kinetic provides a quick and easy interface for showing animation.
But there is one problem. It reads all sprites from a single image. Figuring out sprite coordinates is way too boring.
I have a good news for you: I wrote a software to automate it!
Here is the software:

Windows Application for HTML5 Kinetic Sprite Animation Framing

Web Package – Kinetic Sprite Animation

Here are animation example I made with it (art is not mine, I borrowed it from Xenia’s school homework guidelines – perhaps, it came from some book):

Walk

Sneak

How do you make yours?

  1. Draw sprites in a single image and store the image as png or jpg. Sorry, my application only supports up to 9 sprites. You are welcome to modify it.
  2. Start the application
  3. Push “Load Images” button and load your image. It shall be visible on a screen.
  4. With the left slider, set total number of your sprites.
  5. With the right slider, choose sprites one-by-one. With the left mouse button, drag blue rectangle to frame the first sprite. Use right mouse button + mouse move to resize the box. Sorry, I use same size for all frames. Rationale: I’m too lazy to resize each individual sprite.
  6. Repeat for all frames: select frame with the right slider and move blue rectangle to frame it.
  7. Push Save button to save the result
  8. Unpack “web package”, copy your image to folder walkcycle_4, then in that folder open walkcycle.htm and replace lines like x: 214.666666666667, y: 30.6666666666667, width: 138.666666666667, height: 144.666666666667 with the data you generated and saved.
  9. Change image file name at the end of walkcycle.htm with your image.
  10. Open walkcycle.htm in a browser. It might ask you whether you allow content to be executed. Allow it. Push “Start” button and enjoy.

Sadly, it does not work in Opera. But it works in Google Chrome, Mozilla and IE on my machine.

Dec 27

TI Stellaris and 28byj-48

I had 2 impulsive buying of paperweights collecting dust – TI Stellaris Launchpad and 28byj-48.

The reason for purchase in both cases was dirt-cheap price.

Well, Stellaris is no longer a paperweight – thanks to the guys who wrote Energia

I plug thing together and it did not work. I swapped wires to inputs 1 and 2 and it started spinning. Why is that? I’m not sure, but I have noticed that LEDs on the control board fire in the wrong order, and I foxed it with swapping wires. Now it spins OK.

stellaris

You can see 3 LED ON – it is side effect of digital camera long exposure time. Only 1 or 2 LEDs are ON at a time.

How I’m going to use it? I have no idea. Perhaps, it will go to back to the shelve.

See source code after the break. I did not write it – I found it on the internet and tweaked a bit.

Continue reading

Nov 06

Kinect Face Tracking

It is easy to plug a Kinect to PC – all you need is a cheap adapter. Then you can control something with it.
kinect

Watch the video:
Kinect-to-Arduino-to-Pan-and-tilt

It takes a little bit of programming, but that’s the fun part.
Kinect code is written in C# and run on Win7/64 PC. I use example from Kinect SDK. Arduino part is written in Arduino C. They communicate via Serial-over-USB.

Sadly, it is little too late for Halloween. Never mind, I already have a REALLY CRAZY idea for the next year!

People are asking for source codes. Sure, no problems!

Download All Sources

PC sources include Kinekt project and standalone WinForms project for testing communications with Arduino (testing servo operations from Kinekt is quite inconvinient)

If you want to use Kinekt sources, download the toolkit from MS web site and compare project FaceTrackingBasics-WPF with my sources using something like WinMerge. You will see what did I change.

Arduino part is missing code that checks for non-”0″. But it works. The idea was – if there is bad package, or PC-Arduino get out-of-sync, Arduino shall skip bad data and re-sync. However, code works just fine without it, so I never added the last few lines of code.
(do you remember programming Int14 in MS DOS? That thing required all kind of SW recovery and yet worked unreliably, or maybe I just had some bad hardware). Anyways, I tell to myself: it is not broken, so do not fix it.

Oh, and communication protocol is very simple. PC sends to Arduino 3 bytes over and over:
0×00, X, Y

X and Y are in a range from 1 to 255
